Figure 6, Example – Dell POWEREDGE M1000E User Manual
Page 43
Access Gateway Administrator’s Guide
23
53-1002743-01
Access Gateway mapping
2
FIGURE 6
Example of device mapping to N_Port groups
shows an example of device mapping to specific N_Ports. Note that you can map one or
multiple WWNs to one N_Port to allow multiple devices to log in through one N_Port.
Hosts/Targets
Access Gateway
F_3
F_2
F_1
N_4
WWN1
WWN2
WWN3
F_4
WWN4
WWN5
N_5
F_6
N_6
F_5
N_2
N_1
N_3
PG2
PG1
