Adding and Replacing Parts
111
5 Remove the optical drive, if installed, from the optical drive bay. See "Optical Drive" on page 111.
6 Press the power button to ground the system board.
7 Remove any installed cards from the ExpressCard slot (see "Removing an ExpressCard or Blank" on
page 66) and the 5-in-1 media memory card reader (see "Removing a Media Memory Card" on page 68).
8 Close the display and turn the computer upside down on a flat work surface.
9 Remove the hard drive (see "Hard Drive" on page 112).
Optical Drive
CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
1 Turn the computer over.
2 Remove the optical-drive security screw.
3 Insert a scribe into the notch and push it to the side to release the drive from the bay.
4 Slide the drive out of the bay.
1 battery-bay latch release 2 battery
2 1
