CY7C67200
Document #: 38-08014 Rev. *G
Page 64 of 78
H6
GPIO20/A1
IO
GPIO20: General Purpose IO
A1: HPI A1
F5
GPIO19/A0
IO
GPIO19: General Purpose IO
A0: HPI A0
F6
GPIO15/D15/CTS/
nSSI
IO
GPIO15: General Purpose IO
D15: D15 for HPI
CTS: HSS CTS
nSSI: SPI nSSI
E4
GPIO14/D14/RTS
IO
GPIO14: General Purpose IO
D14: D14 for HPI
RTS: HSS RTS
E5
GPIO13/D13/RXD
IO
GPIO13: General Purpose IO
D13: D13 for HPI
RXD: HSS RXD (Data is received on this pin)
E6
GPIO12/D12/TXD
IO
GPIO12: General Purpose IO
D12: D12 for HPI
TXD: HSS TXD (Data is transmitted from this pin)
D4
GPIO11/D11/MOSI
IO
GPIO11: General Purpose IO
D11: D11 for HPI
MOSI: SPI MOSI
D5
GPIO10/D10/SCK
IO
GPIO10: General Purpose IO
D10: D10 for HPI
SCK: SPI SCK
C6
GPIO9/D9/nSSI
IO
GPIO9: General Purpose IO
D9: D9 for HPI
nSSI: SPI nSSI
C5
GPIO8/D8/MISO
IO
GPIO8: General Purpose IO
D8: D8 for HPI
MISO: SPI MISO
B5
GPIO7/D7/TX
IO
GPIO7: General Purpose IO
D7: D7 for HPI
TX: UART TX (Data is transmitted from this pin)
B4
GPIO6/D6/RX
IO
GPIO6: General Purpose IO
D6: D6 for HPI
RX: UART RX (Data is received on this pin)
C4
GPIO5/D5
IO
GPIO5: General Purpose IO
D5: D5 for HPI
B3
GPIO4/D4
IO
GPIO4: General Purpose IO
D4: D4 for HPI
A3
GPIO3/D3
IO
GPIO3: General Purpose IO
D3: D3 for HPI
C3
GPIO2/D2
IO
GPIO2: General Purpose IO
D2: D2 for HPI
A2
GPIO1/D1
IO
GPIO1: General Purpose IO
D1: D1 for HPI
B2
GPIO0/D0
IO
GPIO0: General Purpose IO
D0: D0 for HPI
F2
DM1A
IO
USB Port 1A D–
E3
DP1A
IO
USB Port 1A D+
C2
DM2A
IO
USB Port 2A D–
D3
DP2A
IO
USB Port 2A D+
G3
XTALIN
Input
Crystal Input or Direct Clock Input
G2
XTALOUT
Output
Crystal output. Leave floating if direct clock source is used.
A5
nRESET
Input
Reset
Table 38.Pin Descriptions (continued)
Pin
Name
Type
Description
