Dell D/Dock Expansion-Station - Manual (Page 7)

NOTE: Docking drivers are installed automatically as part of your operating system.
1. Save any open files.
2. Connect the AC power cable to the expansion station, and connect the expansion station to an electrical outlet.
1 AC power cable
2 expansion station
3. Place the expansion station so that there is enough flat space in front of it to completely support the computer when
the computer is docked.
4. Ensure that the slide lock is in the unlocked position (toward the back of the computer).
5. Hold the computer by its sides and center it against the backstop at the front of the expansion station.
1 backstop
2 docking connector
3 alignment posts
