1 module
2 latch release
1. Ensure the slide lock on the right side of the expansion station is in the unlocked position.
2. Push the latch release on the module and pull out the module from the bay.
Charging a Second Battery in the Module Bay
You can charge your computer's second battery in the D/Dock module bay. A battery light below the module bay displays the
status of the charging battery.
NOTE: If you charge a second battery while the computer is docked, the expansion station charges the battery in the
computer before charging the second battery in the D/Dock module bay.
1. Connect the expansion station to an electrical outlet.
2. Insert a D-Family second battery firmly into the D/Dock module bay and push in the battery latch release to seat the
battery.
