Depth 160 mm (6.30 inches)
Width 312 mm (12.28 inches)
AC Power Input
Voltage 100–240 VAC, 50–60 Hz
Amperage up to 2.0 A
I/0
Serial (DTE) one 9-pin connector, 16550-compatible,
16-byte buffer
Parallel one 25-hole unidirectional, bidirectional,
or ECP connector
PS/2 two 6-pin mini-DIN connectors
USB four 4-pin, USB 2.0-compliant
connectors: three standard USB and one
powered USB
Audio Audio line-out connector for
headphones/speakers
Digital audio S/PDIF
Video:
VGA one 15-hole connector
S-video TV-out one 7-pin mini-DIN connector
Digital video interface (DVI) one 24-hole connector
Network one RJ-45 port; 10/100/1000 GB
Ethernet
Modem one RJ-11 port
Docking (to connect to computer) one connector
PCI one 32-bit, 33 MHz add-in slot
