Palm Rest 67
9 Turn the computer over and remove the four M2.5 x 5-mm screws securing the top of the palm rest.
NOTICE: Release the locking tabs on both sides of the system board connector before attempting to remove the
touch pad or LED cable. Failure to release the locking tabs could result in damage to the cable and/or the cable
connector.
10 Disconnect the touch pad cable.
Use a plastic scribe to release the locking clips on both sides of the system board connector, and then
gently pull to disconnect the touch pad connector from the system board connector.
11 Disconnect the LED board cable.
Use a plastic scribe to release the locking clips on both sides of the system board connector, and then
gently pull to disconnect the LED board connector from the system board connector.
1 M2.5 x 8-mm screws (11)
1
