Display Assembly and Display Latch 57
7 Replace the keyboard (see "Replacing the Keyboard" on page 45).
8 Replace the hinge cover (see "Replacing the Hinge Cover" on page 42).
Display Bezel
Removing the Display Bezel
CAUTION: Before you perform any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as the back panel) on the computer.
1 Follow the instructions in "Preparing to Work Inside the Computer" on page 7.
2 Remove the hinge cover (see "Removing the Hinge Cover" on page 41).
3 Remove the keyboard (see "Removing the Keyboard" on page 43).
4 Remove display assembly (see "Removing the Display Assembly" on page 55).
5 Use a plastic scribe to remove the six rubber bumpers from around the display assembly. It is not
necessary to remove the oval bumpers located on the sides of the display.
6 Remove the six M2.5 x 5-mm screws from around the display assembly.
NOTICE: To avoid damaging the bezel, carefully separate the bezel from the display assembly by starting along the
bottom of the display (near the Dell logo) and working around the edge of the display towards the release latch.
7 Use your fingers to separate the bezel from the display assembly by lifting the inside edge of the bezel
up and away from the center of the display assembly.
