58 Display Assembly and Display Latch
Replacing the Display Bezel
CAUTION: Before you perform any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as the back panel) on the computer.
1 Follow the instructions in "Preparing to Work Inside the Computer" on page 7
2 Follow the instructions in "Removing the Display Bezel" on page 57.
3 Starting near the hinges (near the Dell logo), use your fingers to snap the new bezel into place.
4 Replace the six M2.5 x 5-mm screws to secure the bezel.
5 Replace the six rubber bumpers to cover the screws.
6 Replace the display assembly (see "Replacing the Display Assembly" on page 56).
1 display bezel 2 rubber bumpers (6) 3 M2.5 x 5-mm screws (6)
4 inside edge of bezel
1
2 3
4
