Page 59
Display Assembly and Display Latch
59
7 Replace the keyboard (see "Replacing the Keyboard" on page 45).
8 Replace the hinge cover (see "Replacing the Hinge Cover" on page 42).
Display Panel
Removing the Display Panel
CAUTION:
Before you perform any of the procedures in this section, follow the safety instructions in the
Product
Information Guide.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as the back panel) on the computer.
1 Follow the instructions in "Preparing to Work Inside the Computer" on page 7.
2 Remove the hinge cover (see "Removing the Hinge Cover" on page 41).
3 Remove the keyboard (see "Removing the Keyboard" on page 43).
4 Remove display assembly (see "Removing the Display Assembly" on page 55).
5 Remove the display bezel (see "Removing the Display Bezel" on page 57).
6 Remove the six M2 x 3-mm screws (three on each side)securing the display panel to the display (top)
cover.
7 Gently lift the bottom of the display panel up, then slide the display panel forward to remove it from
the display cover.
