Switch Configuration for Intel® Ethernet FCoE Protocol Driver:
Intel® FCoE/DCB User Guide
NOTES:
In the following examples, the assumption is made that the VLAN and VSAN configurations have already been
performed.
For more installation details check with your switch vendor's documentation:
*
Cisco Nexus* 5000 Series Switch Platform
For the Nexus/Cisco switch platform, a virtual interface is needed to bind the Ethernet port to the FC forwarder or FCF. Assume
port 1/3 in the following example.
Commands to enable trunk mode for an Ether port:
configure
interface ethernet 1/3
switchport mode trunk
spanning-tree port type edge trunk
exit
Commands to create a VFC:
configure
interface vfc 3
bind interface ethernet 1/3
no shutdown
exit
Brocade* 8000 Series FCoE Switch
For the Brocade 8000 series FCoE switch, assuming port 1/3, vlan 101 for FCoE, use:
configure terminal
interface TenGigabitEthernet 1/3
switchport
switchport mode converged
vlan classifier activate group 1 vlan 101
no shutdown
cee default
exit
NOTES: The "cmsh" command must be issued before the "configure terminal" command will function properly.
.
