NOTE: The Compatibility Manager feature is available on versions 3.2 and later of the appliance software stack.
See the
Dell PowerVault DL Backup to Disk Appliance Interoperability Guide at support.dell.com/manuals for
supported DL2 xxx platforms.
Enclosure Numbers
The backup application and Server Administrator refer to the MD xxxx storage enclosures by enclosure numbers.
Windows storage management applications refer to the enclosure by the bus number. The enclosure number and bus
number refer to the same enclosure.
PERC 6/E
• The first enclosure attached to port 0 of the PERC 6/E adapter is 0. Additional enclosures daisy-
chained off the first enclosure are numbered 1 and 2 respectively.
• The first enclosure attached to port 1 of the PERC 6/E adapter is 3. Additional enclosures attached to
this enclosure are numbered 4 and 5 respectively.
PERC
H800
• The first enclosure attached to port 0 of the PERC H800 adapter is 0. Additional enclosures daisy-
chained off the first enclosure are numbered 1, 2, and 3 respectively.
• The first enclosure attached to port 1 of the PERC H800 adapter is 4. Additional enclosures attached
to this enclosure are numbered 5, 6, and 7 respectively.
Internal PERC adapters such as the PERC 6/i and H700 are assigned the enclosure number 255.
