Installation
CSX400 and CSX400-DC User’s Guide 65
Materials Required
The following parts are included with the CSX400:
• Left (P/N 8501242-01) and right (P/N 8501241-01) rackmount brackets ( Figure 16 ).
• 6-32 x 1/4 inch flat-head screws (4)
Figure 16 CSX400 and CSX400-DC Rackmount Hardware
Attaching the Rackmount Brackets to the CSX400
Refer to Figure 17 and proceed as follows to attach the rackmount brackets:
1. Remove and save the four 6-32 x 1/4 inch flat-head screws that are located along the front edges
of each side of the CSX400.
2. Locate the two rackmount brackets from the package included with your CSX400.
!
CAUTION
Do not use screws other than those supplied with the CSX400 to perform the following
procedures.
Rackmount Brackets (2)
