MIB Navigator
CSX400 and CSX400-DC User’s Guide 199
circuitmap:
Syntax: circuitmap -a
circuitmap -f
circuitmap -d
circuitmap -s
Description: Allows the user to view and/or modify a Protocol’s Circuit Map (i.e.,
address-to-circuit) table for the device. The -a option shows the user the
current Host Map information for the device. The -d option allows the
user to delete an entry from the table. The -s option allows the user to
insert a static entry into the table. The -f option allows the user to flush
the table. The device must be initialized after changing the Circuit Map.
Options: Not Applicable
Example:
ppp:
Syntax: ppp
Description: Provides additional status relating to PPP and its Network Control
Protocols.
Options: Not Applicable
Node
00:00:1d:23:a1:5b
00:00:1d:23:a1:5b
Circuit ID
203
102
# Interface
# 2
# 2
Network
5A4C212B
00000172
MIBNav-> circuitmap -s IPX 2 00000172 00:00:1d:02:d1:7a 102
MIBNav-> circuitmap -a
circuitmap
