General Configuration Using Local Management
CSX400 and CSX400-DC User’s Guide
169
To enable SAP Routing, complete the following steps:
1.
From the IPX Configuration screen, highlight IPX SAP and then press ENTER.
The IPX SAP Configuration screen, shown in
, displays.
2.
Use the arrow keys to highlight the Port option.
3.
Type in the number of the port that you wish to enable SAP routing, then press ENTER.
4.
Use the arrow keys to highlight the Port Level SAP option.
5.
Use the ENTER key to toggle the entry to ENABLED.
6.
Use the arrow keys to highlight the SAVE command field at the bottom of the screen, and then
press ENTER. The message “SAVED OK” displays.
Figure 71
IPX SAP Configuration Screen
System Level SAP:
Port Level SAP:
RETURN
SAVE
+PORT-
DISABLED
DISABLED
IPX Address: xxx.xxx.xxx.xxx
Port:
1
CSX400 Local Management
Flash Image Version XX.XX.XX
IPX SAP CONFIGURATION
