WPIM Cable Specifications
CSX400 and CSX400-DC User’s Guide 233
WPIM-DDS
This section provides Cabletron Systems part number and connector specifications for the
WPIM-DDS interface cable. The WPIM-DDS has one RJ45 port for a direct connection to a single
Digital Data Service (DDS) circuit.
Table 48 provides cable and interface type, and part number information for the WPIM-DDS
interface cable, and Table 49 provides network Pin Assignment information for the DDS interface
cable.
. Table 48 DDS Interface Cable Part Number
Cable and Interface Type Part Number
DDS 9360119
Table 49 Network Pinout Assignments
PIN SIGNAL
1 Transmit Ring
2 Transmit Tip
3 Not Used
4 Not Used
5 Not Used
6 Not Used
7 Receive Tip
8 Receive Ring
