CSX400 Configuration with QuickSET
CSX400 and CSX400-DC User’s Guide 89
The line configuration information shown in Table 15 is determined by your service provider. The
CSX400 factory default settings are in bold.
The following definitions explain the fields in the Synchronous WAN configuration window.
Sync Port Type — Displays the Synchronous port electrical interface type. The selections for
this field are V.35, RS422, RS232, and X.21. The default setting for this field is V.35. Table 16
explains the options for the Sync Port Type.
Table 15 Telco Configuration Information
Configuration
Information Required by
User
Configuration Information
Supplied by Service Provider
Sync Port Type V.35, RS422, RS232 or X.21
Sync Flow Control
Force CTS on or off
Force DSR on or off
Sync Clock Speed 64000
Table 16 Sync Port Types
Sync Port Type
Interface
Type
Cable Type
Cabletron
Part Number
RS422 RS449 RS449 9380120
RS232 RS232 RS232 9380122
V.35 V.35 V.35 9380121
X.21 X.21 X.21 9380123
RS422 RS530 RS530 9380124
RS422 RS530A RS530A 9380126
RS422 RS530 Alt A RS530 Alt A 9380125
RS422 RS530A Alt A RS530A Alt A 9380127
