Humboldt H-4114SD.3F Electrical Density Gauge User Manual

Page 37

Pressing the Data button

will present you with the

following screen:

The EDG features Blue Tooth Capabilities, So if you computer works with

Blue Tooth enabled hardware, you can access the data in your EDG and

transfer it to your computer for use with the EDG software. To be able to

import data to your computer via Blue Tooth, you must turn on the Blue

Tooth Connection. This is accomplished by Pressing the ON next to Blue

Tooth Connection.

Once on, the radio button next to the word ON will be highlighted in Blue

and the Blue Tooth Logo

will appear at the top left-hand corner of the

screen and the Power Light above the Power Button on the console will be

blinking with a Blue light.

Data can also be transferred to a computer by using the USB port located

above and to the left of the Touch Screen. The EDG comes supplied with

a USB thumb drive, which can be used to transfer files to a computer or

another gauge.
