Dell OptiPlex 760 User Manual
Page 118
13.
Route the floppy drive cable through the securing tab on the heat sink and connect it to the system board.
14.
Replace the optical drive (see
Optical Drive
).
15.
Replace the computer cover (see
Replacing the Computer Cover
).
Back to Contents Page
1 heat sink assembly
2 heat-sink assembly bracket
3 captive screw in housing (2)
