Multi-function Drill Control
38h
Tramlining
The display defaults to the channel after 10 seconds (unless the Area Total was selected).
There are five systems of tramlining - symmetric, asymmetric left, asymmetric right, 10 bout and 18 bout. The
tramline bout is programmable from 1 to 15 in symmetric, asymmetric left and asymmetric right sequences.
Selection of asymmetric tramlining is denoted by a decimal point on the display between the current bout
number on the left and the tramline bout number on the right. Left or right asymmetric tramlining is selected in
the programming mode.
NOTE: There is an option in the program mode to disable the tramline function altogether.
Manually advance the bout number
Press to advance the current bout number by 1.
Hold the bout number
Press to 'hold' the current bout
when the drill goes out of work.
The display will flash 'StOP'.
Press again to resume the normal bout sequence.
Turn tramlining off
1. Press and hold the button while plugging the instrument into a
power source to enter program mode 2.
2. Press Select the channel.
3. PRESS to select 0 (Off) / 1 (On).
4. Unplug the instrument, then plug in again to resume the normal display
mode.
Figure N
Advance bout number
Indicates
asymmetric
sequence
Figure O
Hold bout number
Figure P
Turn tramlining off
