Multi-function Drill Control

38f


Area Total / Implement Width

The area is derived from the forward speed and the programmed
implement width and is accumulated to whichever total is selected on the
display – total 1 or total 2.

Area will only accumulate while the drill is in work, i.e. forward speed is
being registered.

The two separate area totals can be independently reset to zero.

Display Area Total

1.

Select the channel.


2.

Press to cycle between the two area totals.


The display will then show ‘tot.1’ or ‘tot.2’ before displaying the area
accumulated since that total was last reset.

Reset Totals


1.

Select the channel.


2.

Press to cycle between the two area totals.


3.

Hold for 5 seconds to zero that total.











Figure I

Display Area Total

Figure J

Select Total 1 or Total 2

Figure K

Reset Total
