67

8-10m Press Range

Operating Instructions

7. Parts and Assembly

AS4276

PRESS 8-10 AIR BRAKE LAYOUT

ITEM

PART NO

DESCRIPTION

QTY

COMMENTS

52

P15534

AIR FITTING 90° M16

1

53

P15861

HOSE

4

54

P16202

SPIRAL WRAP 1M 27X32OD

1

55

P16989

AIR TANK 30L

1

56

P16991

STR FITTING - 16mm HOSE

2

57

P16994

AIR TANK SPACER PLATE

4

58

P16996

TEST POINT M22

1

59

P16997

16MM AIR HOSE X 110MM

1

60

P16998

16mm AIR HOSE x 650mm

1

61

P16999

RED AIR HOSE 2600mm

1

62

P17001

RED AIR HOSE 800mm

1

63

P17003

RED AIR HOSE 4000mm

1

64

P17004

YELLOW AIR HOSE 4000mm

1
