8-10m Press Range

Operating Instructions

32

4. Adjustment / Operation

1x

Silver

51mm

1x

Black

29mm

1x

Yellow

20mm

Wheel Height Cylinder

Out-Rigger Adjuster

1x

Silver

51mm

1x

Red

10mm

1x

Black

29mm

Lev. Board Cylinders

X-Press

Starting Settings

Disc Angling Cylinder

1x

Silver

51mm

Rear Roll Cylinder

Red

10mm

1x

Black

29mm

1x
