171

8-10m Press Range

Operating Instructions

7. Parts and Assembly

AS2347

CULTIPRESS

LEVEL BOARD RH INNER ASSEMBLY

ITEM

PART NO

DESCRIPTION

QTY

COMMENTS

1

P13987

LEVEL BOARD RH INN

1

2

P13416

SPRUNG LEAF 80x10

10

3

P13417

BELLOTA W/PLATE 80mm

10

4

P13407

NUT TOOTHED M10

20

5

P13406

BOLT M10x35 DOME SQ.

20

6

P13402

LEAF CLAMP 60x60 RHS

10

7

P02007

NUT LOCK M12

10

8

P02601

WASHER FLAT M12

10

9

P07545

PLASTIC END CAP 60x60

2

10

P08866

BOLT M12x110 GR8.8

10

11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
