51 8-10m Press Range
Operating Instructions
7. Parts and Assembly
AS4263
TOP LEVEL ASSEMBLY 10m
CULTIPRESS
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2001 LEVELLING BOARD 8m 1
2 AS2041 WING FOLD HYDRAULIC CIRCUIT 1 P14285
3 AS2042 WHEEL CYLINDERS AND REAR ROLL 1
4 AS2318 WING EXTENSION RH 1
5 AS2319 WING EXTENSION LH 1
6 AS2336 ROLL ASSEMBLY RH INNER 1
7 AS2337 ROLL ASSEMBLY RH OUTER 1
8 AS2338 ROLL ASSEMBLY LH INNER 1
9 AS2339 ROLL ASSEMBLY LH OUTER 1
10 AS2341 ROLL ASSEMBLY RH 1m 1
11 AS2342 ROLL ASSEMBLY LH 1m 1
12 AS3733 CP- 8/10M STICKER LAYOUT 1
13 AS3930 LH 1m TINE FRAME ASSEMBLY 1
14 AS3931 RH 1m TINE FRAME ASSEMBLY 1
15 AS3932 LH TINE FRAME ASSEMBLY 1
16 AS3933 RH TINE FRAME ASSEMBLY 1
17 AS3984 MAIN SPINE ASSEMBLY 1
18 AS4029 TILT CIRCUIT HYDRAULIC LAYOUT 1
19 AS4270 DRAWBAR ASSEMBLY 1
20 AS4275 PRESS 8-10 HYD BRAKE LAYOUT 1
21 AS4277 WING ASSEMBLY RH 1
22 AS4278 WING ASSEMBLY LH 1
23 P18140 MANUAL - CP/XP 2011 1
