107 8-10m Press Range
Operating Instructions
7. Parts and Assembly
AS2316 ROLL ASSEMBLY RH 1m - X-PRESS
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS1974 DD700 5 RING AXLE 1
2 AS1997 PILLAR 700DD 1
3 AS2174 700 DD STYLE BEARING ON OPPOSITE SI 1
4 AS2327 LEVEL BOARD RH 1m ASSEMBLY 1
5 P00003 BOLT M12x40 GR. 8.8 8
6 P00019 BOLT M24x120 GR. 8.8 3 STRUCTURAL
7 P02007 NUT LOCK M12 12
8 P02008 NUT LOCK M16 'TYPE T' 8 DIN 985
9 P02009 NUT LOCK M20 4
10 P02010 NUT LOCK M24 3
11 P02011 NUT LOCK M30 2
12 P02601 WASHER FLAT M12 4
13 P02602 WASHER FLAT M16 16
14 P02603 WASHER FLAT M20 8
15 P02604 WASHER FLAT M24 Ø50 6
16 P02608 WASHER FLAT M30 2
17 P02654 BOLT M20x65 GR. 8.8 4
18 P04179 WASHER FLAT M12 Ø38 16
19 P07922 BUSH SPRUNG - Ø32xØ26x15 8
20 P08802 SHIM KIT 7 PIECE 2
21 P10636 BUSH SPRUNG - Ø40xØ31x20 1
22 P11299 BOLT M12x90 DOME SQ. 4
23 P12765 BOLT M30x120 GR. 8.8 2
24 P12787 BOLT M16x75 GR8.8 8
25 P13403 SCRAPER STEM 2
26 P13409 SCRAPER - NEW PRESS 2
27 P13426 ROLL FRAME LEAF 2
28 P13507 SCRAPER 1+1/2 NEW PRESS 2
29 P13896 LEAF MOUNT 1
30 P13898 CLAMP PLATE 4
31 P13911 SCRAPER STEM CRANKED 2
32 P13957 LEAF MOUNT 1
33 P13966 ROLL FRAME RH 1m 1
34 P15081 ROLL FRAME BRACE BAR 1
35 P15084 WING ADAPTER 1
36 P17154 SCRAPER CLAMP PLATE 4
