165

8-10m Press Range

Operating Instructions

7. Parts and Assembly

AS2348

CULTIPRESS

LEVEL BOARD RH OUTER ASSEMBLY

ITEM

PART NO

DESCRIPTION

QTY

COMMENTS

1

P13988

LEVEL BOARD RH OUT

1

2

P13416

SPRUNG LEAF 80x10

6

3

P13417

BELLOTA W/PLATE 80mm

6

4

P13407

NUT TOOTHED M10

12

5

P13406

BOLT M10x35 DOME SQ.

12

6

P13402

LEAF CLAMP 60x60 RHS

6

7

P02007

NUT LOCK M12

6

8

P02601

WASHER FLAT M12

6

9

P07545

PLASTIC END CAP 60x60

2

10

P08866

BOLT M12x110 GR8.8

6

11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
