137 8-10m Press Range
Operating Instructions
7. Parts and Assembly
AS2174
700 DD STYLE BEARING ON OPPOSITE
SIDE
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00057 BOLT M16x60 GR. 8.8 4
2 P01638 BOLT M20x160 GR. 8.8 4
3 P02008 NUT LOCK M16 'TYPE T' 4 DIN 985
4 P02009 NUT LOCK M20 4
5 P02602 WASHER FLAT M16 8
6 P02603 WASHER FLAT M20 8
7 P05431 BEARING - PRESSED Ø61x56 1
8 P13424 PILLAR U BOLT STYLE 1
9 P13849 CLAMP PLATE 1
