131 8-10m Press Range
Operating Instructions
7. Parts and Assembly
AS1953
AXLE ASSEMBLY-DD700 8 RING 1
OVERHUNG
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P01698 NUT CASTLE M60 1
2 P02489 PIN SPLIT Ø10x100 1
3 P07730 AXLE Ø60x1837 1
4 P08188 DD 600 - SPOOL 5
5 P08189 DD 600 - BEARING SPOOL 4
6 P08190 DD 600 - NUT SPOOL 2 J220112880
7 P08191 DD 600 - INTERNAL SPACER 8
8 P08994 DD RING Ш700 16
