42 ADC2350/E and ADC2350B/BE Table of Contents Index Great Plains Manufacturing, Inc.
167-085M Table of Contents Index 2012-08-01
Assembly Weight for ADC2350/E Air Cart Plus CTA4000HD
a
a. Data includes standard (four) weight kits, but does not include markers.
CTA4000HD Model -8006 (6in) -6576 (7.5in) -5010 (10in)
ADC2350/E Empty 28653 lbs (12997 kg) 27340 lbs (12401 kg) 26148 lbs (11861 kg)
ADC2350/E Full 51053 lbs (23157 kg) 49740 lbs (22562 kg) 48548 lbs (22021 kg)
Assembly Weight for ADC2350/E Air Cart Plus NTA3010
a
a. Data does not include markers.
CTA3010 -3610 (10in) -4875 (7.5in)
Rows ADC2350B/BE Empty ADC2350B/BE Full ADC2350B/BE Empty ADC2350B/BE Full
No Weight Kits 23800 lbs (10795 kg) 46200 lbs (20956 kg) 25750 lbs (11680 kg) 48150 lbs (21840 kg)
1 Weight Kit 25200 lbs (11431 kg) 47600 lbs (21591 kg) 27150 lbs (12315 kg) 49550 lbs (22476 kg)
2 Weight Kits 26600 lbs (12066 kg) 49000 lbs (22226 kg) 28550 lbs (12950 kg) 50950 lbs (23111 kg)
3 Weight Kits 28000 lbs (12701 kg) 50400 lbs (22861 kg) 29950 lbs (13585 kg) 52350 lbs (23746 kg)
4 Weight Kits 29400 lbs (13336 kg) 51800 lbs (23496 kg) 31350 lbs (14220 kg) 53750 lbs (24381 kg)
Assembly Weight for ADC2350/E Air Cart Plus NTA3510
a
a. Data does not include markers.
CTA3510 -4010 (10in) -5575 (7.5in)
Rows ADC2350B/BE Empty ADC2350B/BE Full ADC2350B/BE Empty ADC2350B/BE Full
No Weight Kits 24600 lbs (11158 kg) 47000 lbs (21319 kg) 26900 lbs (12202 kg) 49300 lbs (22362 kg)
1 Weight Kit 26000 lbs (11793 kg) 48400 lbs (21954 kg) 28300 lbs (12837 kg) 50700 lbs (22997 kg)
2 Weight Kits 27400 lbs (12428 kg) 49800 lbs (22589 kg) 29700 lbs (13472 kg) 52100 lbs (23632 kg)
3 Weight Kits 28800 lbs (13063 kg) 51200 lbs (23224 kg) 31100 lbs (14107 kg) 53500 lbs (24267 kg)
4 Weight Kits 30200 lbs (13698 kg) 52600 lbs (23859 kg) 32500 lbs (14742 kg) 54900 lbs (24902 kg)
Assembly Weight for ADC2350B/BE Air Cart Plus 3N-4010HDA
3N-4010HDA -4810 (10in) -6675 (7.5in)
Cart ADC2350B/BE Empty ADC2350B/BE Full ADC2350B/BE Empty ADC2350B/BE Full
Standard Drill & Cart 30984 lbs (14054 kg) 53384 lbs (24215 kg) 31098 lbs (14106 kg) 53498 lbs (24266 kg)
1 Weight Kit
a
& Cart
a. Each weight kit assumed to be populated with ten 100-pound weights (5 weights each bracket).
32105 lbs (14563 kg) 54505 lbs (24723 kg) 32219 lbs (14614 kg) 54619 lbs (24775 kg)
Dual Markers & Cart 32844 lbs (14898 kg) 55244 lbs (25058 kg) 32958 lbs (14949 kg) 55358 lbs (25110 kg)
2 Weight Kits & Cart 33227 lbs (15071 kg) 55627 lbs (25232 kg) 33341 lbs (15123 kg) 55741 lbs (25284 kg)
Markers, 1 Kit & Cart 33965 lbs (15406 kg) 56365 lbs (25567 kg) 34079 lbs (15458 kg) 56479 lbs (25618 kg)
3 Weight Kits & Cart 34348 lbs (15580 kg) 56748 lbs (25741 kg) 34462 lbs (15632 kg) 56862 lbs (25792 kg)
Markers, 2 Kits & Cart 35086 lbs (15915 kg) 57486 lbs (26075 kg) 35200 lbs (15967 kg) 57600 lbs (26127 kg)
Markers, 3 Kits & Cart 36208 lbs (16424 kg) 58608 lbs (26584 kg) 36322 lbs (16475 kg) 58722 lbs (26636 kg)
