52 / TROUBLESHOOTING
CONNECTOR PIN-OUTS
PM332 Implement Accessory Harness
Pin #
Description
1 Lift Switch (light green)
2 Hopper # 1 (brown)
3 Hopper # 2 (light blue)
4 Frequency (orange)
5 +8 V Acc Power (yellow)
6 + 12 V Acc Power (purple)
7 Acc Return (gray)
8 RS-232 Rx (pink)
9 RS-232 Tx (neutral)
PM400 Implement 1
Pin #
Description
1 Row 1 (green)
2 Row 2 (brown)
3 Row 3 (blue)
4 Row 4 (orange)
5 Row 5 (yellow)
6 Row 6 (violet)
7 Row 7 (gray)
8 Row 8 (pink)
9 Row 9 (tan)
10 Row 10 (white/black)
11 Row 11 (red/black)
12 Row 12 (green/black)
13 Row 13 (orange/black)
14 Row 14 (blue/black)
15 Row 15 (black/white)
16 Row 16 (red/white)
17 Row 17 (green/white)
18 Row 18 (blue/white)
19 Row 19 (black/red)
20 Row 20 (white/red)
21 Row 21 (orange/red)
22 Row 22 (blue/red)
23 Row 23 (red/green)
24 +8 V Snsr Pwr Left (red)
25 +8 V Snsr Pwr Right (red)
PM400 Implement 2
Pin #
Description
1 Row 25 (green)
2 Row 26 (brown)
3 Row 27 (blue)
4 Row 28 (orange)
5 Row 29 (yellow)
6 Row 30 (violet)
7 Row 31 (gray)
8 Row 32 (pink)
9 Row 33 (tan)
10 Row 34 (white/black)
11 Row 35 (red/black)
12 Row 36 (green/black)
13-23 No connection
24 8 V sensor power (red/black/white)
25 8 V sensor power (red)
26 Sensor return (white/black/red)
27 Sensor return (black)
28 No connection
29 No connection
30 No connection
31 No connection
32 No connection
33 No connection
34 No connection
35 No connection
36 No connection
37 No connection
PM400 Implement 1 (continued)
Pin #
Description
26 Sensor return left (black)
27 Sensor return right (black)
28 Row 24 (orange/green)
29 Hopper 1 (black/white/red)
30 Hopper 2 (green/black/white)
31 Shaft/Fan/Flow (orange/black/white)
32 8V power (red)
33 12V switched power (black/red/green)
34 Sensor return (black)
35 RS-232 RX (red/black/green)
36 RS-232 TX (green/black/orange)
37 Lift switch (white)
