OPERATOR’S MANUAL
PM300, PM332, PM400 Planter Monitors
11001-1372-200606
KEY FUNCTIONS / 17
GROUND SPEED SETUP KEY
The Ground Speed Setup key is used to navigate to the Ground Speed
Setup screen for input of the ground speed calibration (or manual entry of
ground speed calibration number), manual ground speed (used if no ground
speed is available), and ground speed maximum limit (optional).
If data on another screen is changed, it is saved when this key is selected.
LIMITS SETUP KEY
The Limits Setup key is used to navigate to the Limits Setup screen for
input of the upper limit (optional), target population value (optional), lower
limit (optional), population adjustment factor (optional for sensors that count
less than 100% of all seeds), and response rate (optional to increase or
decrease the console’s response rate).
If data on another screen is changed, it is saved when this key is selected.
DISPLAY AND SERVICE KEY
The Display And Service key is used to navigate to the Display & Service
Setup screen for access to the function, row indicators, service, and
security sub-menus; English/Metric units selection; display backlight
intensity; and alarm volume.
If data on another screen is changed, it is saved when this key is selected.
ACCESSORY SETUP KEY
The Accessory Setup key is used to navigate to the Accessory Setup
screen for selection of a fan (RPM) / shaft (RPM) / or flow (G/MIN or L/min)
labels, upper and lower alarm limits, and calibration (or manual calibration
number entry).
If data on another screen is changed, it is saved when this key is selected.
SEED COUNT MODE KEY
The Seed Count Mode key is used to navigate to the Seed Count screen.
This mode allows users to test planters for proper operation prior to field
use.
If data on another screen is changed, it is saved when this key is selected.
SPEED AREA MODE KEY
The Speed Area Mode key is used to navigate to the Speed Area
Distance screen. This mode allows use of the console for non-planting
operations. This mode is also used to start, stop, or clear the three
independent area accumulators (FIELD AREA 1, FIELD AREA 2, and
TOTAL AREA).
If data on another screen is changed, it is saved when this key is selected.
GROUND
SPEED
SETUP
LIMITS
SETUP
DISPLAY
&
SERVICE
ACCY
SETUP
SEED
COUNT
MODE
SPEED
AREA
MODE
Ground Speed Setup key
Limits Setup key
Display and Service key
Accessory Setup key
Seed Count Mode key
Speed Area Mode key
