OPERATOR’S MANUAL
PM300, PM332, PM400 Planter Monitors
11001-1372-200606
INTRODUCTION / 5
SPECIFICATIONS
Power 10–16 VDC, 5 A maximum
Operating temperature range -20°C to 70°C (-4°F to 158°F)
Storage temperature range -40°C to 85°C (-40°F to 185°F)
Size 18.4 cm W x 20.1 cm H x 4.3 cm D
(7.3" W x 7.9" H x 1.7" D)
Weight 4.4 lbs for 16-row PM300 system
4.8 lbs for 32-row PM332 system
6.4 lbs for 36-row PM400 system
*Weight includes console and attached
cables (battery power cable and signal
cable that extends to the drawbar).
Wire Harnesses The PM300, PM332, and PM400 include
integrated harnesses to supply the unit's
power (fused), ground speed input, and
sensor inputs (to drawbar). The connectors
are compatible with existing DICKEY-john
harnesses. DICKEY-john can supply
custom harnesses required for sensor
inputs.
Sensors Compatible with existing DICKEY-john
sensors
Standard mounting Rear attached horizontal or vertical
mounting bracket
Mounting bracket weighs 1.0 lb.
Optional mounting Three-axis adjustable mounting bracket
Contrast adjustment Automatic temperature compensation for
contrast
Backlight adjustment Three settings for full sun, daytime, or
nighttime use
CE certified
Dust and moisture resistant
