SARGENT Profile Series Exit Devices - Manual (Page 2)

800-810-WIRE (9473) • www.sargentlock.com • A7455B
Profile Series Exit Device
Copyright © 2003, 2008, Sargent Manufacturing Company
, an A
SSA ABL
O
Y
Group company
. All rights reserved.
Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
Table of Contents
Page
Warning and Items Supplied . . . . . . . . . . . . . . . . . . . 1
Parts Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Rim Installation Instructions . . . . . . . . . . . . . . . . . 4-7
Mortise Installation Instructions . . . . . . . . . . . . . 8-11
Operational Check . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Basic Programming Instructions . . . . . . . . . . . . 12-21
Chain Programming . . . . . . . . . . . . . . . . . . . . . . . . . 22
Transaction Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Supplemental - Individual Door Log Sheet . . . . . . . 24
1
2
3
4
5
6
7
8
9
