*E 417547 See ECN RXU Converted from Preliminary to Final.
Changed address of Cypress Semiconductor Corporation on Page# 1 from “3901
North First Street” to “198 Champion Court”.
Changed I
X
current value in MODE from –5 & 30
μA to –30 & 5 μA respectively
and also Changed I
X
current value in ZZ from –30 & 5
μA to –5 & 30 μA respec-
tively on page# 19.
Modified test condition in note# 8 from V
IH
< V
DD
to V
IH
< V
DD.
Modified “Input Load” to “Input Leakage Current except ZZ and MODE” in the
Electrical Characteristics Table.
Replaced Package Name column with Package Diagram in the Ordering
Information table.
Replaced Package Diagram of 51-85050 from *A to *B
Updated the Ordering Information.
*F 473650 See ECN VKN Added the Maximum Rating for Supply Voltage on V
DDQ
Relative to GND.
Changed t
TH
, t
TL
from 25 ns to 20 ns and t
TDOV
from 5 ns to 10 ns in TAP AC
Switching Characteristics table.
Updated the Ordering Information table.
*G 2447027 See ECN VKN/AESA Corrected typo in the Ordering Information table
Corrected typo in the CY7C1447AV33 ‘s Logic Block diagram
Updated the x72 block diagram
Document Title: CY7C1441AV33/CY7C1443AV33/CY7C1447AV33 36-Mbit (1M x 36/2M x 18/512K x 72) Flow-Through SRAM
Document Number: 38-05357
REV. ECN NO. Issue Date
Orig. of
Change Description of Change
