CY7C1441AV33
CY7C1443AV33,CY7C1447AV33
Document #: 38-05357 Rev. *G Page 25 of 31
Figure 6. ZZ Mode Timing [28, 29]
Timing Diagrams (continued)
t
ZZ
I
SUPPLY
CLK
ZZ
t
ZZREC
A LL INPUTS
(except ZZ)
DON’T CARE
I
DDZZ
t
ZZI
t
RZZI
Outputs (Q)
High-Z
DESELECT or READ Only
Note
28. Device must be deselected when entering ZZ mode. See Cycle Descriptions table for all possible signal conditions to deselect the device.
29. DQs are in high-Z when exiting ZZ sleep mode.
