ARCMASTER ® 160TS
March 31, 2006 3-6
3.05 Power Source Features
Feature Description
New Digital Control • Almost all welding parameters are adjustable
Touch Panel Switches • Touch switches eliminate mechanical damage
Front Control Cover • Protects front panel controls
Digital Meter
• Displays selected weld parameter value
• Displays weld current when welding
• Displays weld current for 20 seconds after weld has been
completed
• A selected weld parameter value can be adjusted at any time
even while welding
ON/OFF switch • Primary voltage Supply ON/OFF switch located on rear panel
Voltage Reduction Device (VRD)
(shipped de-activated, Field Capable)
see Section 11 for Activation Instructions
Reduces the OCV when the power supply is not in use. Eliminates the
need for add on voltage reducers and has no effect on arc starting.
• VRD fully complies to IEC 60974-1
• When Stick mode is selected the green VRD light is ON when
not welding and red when welding.
• When in TIG modes VRD is off.
Control Knob
• For the selected weld parameter, rotating the knob clockwise
increases the parameter
• Rotating the knob counterclockwise decreases the parameter
• A selected weld parameter value can be adjusted at any time
even while welding
• Pushing the knob in displays actual arc voltage.
Self Diagnosis Using Error Codes
• An error code is displayed on the Digital Meter when a problem
occurs with Primary supply voltage or internal component
problems. Refer to troubleshooting guide.
Save/Load function
• A total number of 5 programs can be saved into the LM-200
memory
SAVE the Current Weld Parameters into Memory
• Press the SAVE button
• Select a memory location by rotat ing the control knob, 1 to 5
is dis played on the meter
• After selecting the desired memory location (ie. 1 to 5), press
the parameter button and the machine give a beep to confi rm
the weld parameters from the control panel are saved.
LOAD (retrieve) a Program to Control Panel
• Press the LOAD button
• Select a memory location by rotat ing the control knob, 1 to 5
is dis played on the meter
After selecting the desired memory location (ie. 1 to 5), press the
parameter button and the machine give a beep to confi rm the weld
parameters are loaded onto the control panel
