ARCMASTER ® 160TS
March 31, 2006 3-5
3.04 Weld Parameters for ArcMaster 160TS
Weld Mode
Weld
Parameter Parameter Range
Factory
Setting
Incremental
Unit STICK
HF
TIG LIFT TIG
PRE-FLOW 0.0 to 1.0 sec 0.1 sec 0.1 sec No Yes Yes
HOT START 0 to 70A 20A 1A Yes Yes No
INITIAL CUR. 1 to 160A 30A 1A No Yes Yes
UP SLOPE 0 to 15 sec 1 sec 0.1 sec No Yes Yes
PEAK CUR. 1 to 160A 120A 1A No Yes Yes
WELD CUR
1 to 160A 230V
1 to 85A 115V
80A
80A
1A
1A
Yes
Yes
Yes
Yes
Yes
Yes
SPOT TIME 0.5 to 5.0 sec 2 sec 0.1 sec No Yes No
PULSE WIDTH 15 to 80% 50% 1% No Yes Yes
PULSE FREQ. 0.5 to 500Hz 100.0Hz See Table 6 No Yes Yes
DOWN SLOPE 0 to 25 sec 3 sec 0.1 sec No Yes Yes
CRATER CUR. 1 to 160A 30A 1A No Yes Yes
POST-FLOW 0.0 to 60 sec 10 sec 0.1 sec No Yes Yes
Table 5 – Weld Parameters for ArcMaster 160TS
PULSE FREQ. Range Incremental Unit
0.5 to 20Hz 0.1Hz
20 to 100Hz 1Hz
100 to 500Hz 5Hz
Table 6 – PULSE FREQ. Range and Incremental Units
