Fabricator 181i
Manual 0-51 91 2-5 INTRODUCTION
NOTE
The recommended time delay fuse or circuit breaker size is 50 amp. An individual branch circuit capable
of carrying 50 amperes and protected by fuses or circuit breaker is recommended for this application.
Fuse size is based on not more than 200 percent of the rated input amperage of the welding Power
Source (Based on Article 630, National Electrical Code)
Tweco continuously strives to produce the best product possible and therefore reserves the right to
change, improve or revise the speci fications or design of this or any product without prior notice. Such
updates or changes do not entitle the buyer of equipment previously sold or shipped to the correspond-
ing changes, updates, improvements or replacement of such items.
The values specified in the table above are optimal values, your values may differ. Individual equipment
may differ from the above specifications due to in part, but not exclusively, to any one or more of the
following; variations or changes in manufactured components, installation location and conditions and
local power grid supply conditions.
The thermal protection switch is rated at 80°C.
2.10 Options and Accessories
DESCRIPTION PART NUMBER
Tweco Fusion 180A MIG Gun, 12ft (3.6m) Length F180TA-12-3035
Tweco Spool Gun 160A,12ft (3.6M) Length, suits 4" (100mm) spools for aluminum welding SG160TA-12-3035
TIG Torch, 17V, 12.5 ft, 8 pin and accessory kit with 1/16", 3/32", 1/8" thoriated
tungstens; 1/16", 3/32", 1/8" collets; 1/16", 3/32", 1/8" collet bodies; No. 5, 6, 7 Alumina
nozzle; short back cap; long back cap
W4013802
Fabricator 141i-181i Carry Bag W4015301
Basic 4 Wheel Cart W4014700
Foot Control for remote amperage control when TIG welding 600285
Tweco WeldSkill Auto-Darkening Helmet Skull & Fire (USA Only) 4100-1004
Drive Roll .023" - .035" (0.6-0.9mm) V groove for steel & stainless steel W4014800
Drive Roll .023"- .030" (0.6-0.8mm) V groove for steel & stainless steel wires [Fitted] 7977036
Drive Roll .035"/.045" (0.9/1.2mm) V groove for steel & stainless steel wires 7977660
Drive Roll .030"-.035" (0.8-0.9mm) U grooved for aluminum wires 7977731
Drive Roll .040"-.045" (1.0-1.2mm) U grooved for aluminum wires 7977264
Drive Roll .030"-.035" (0.8-0.9mm) V knurled groove for flux cored wires 7977732
Drive Roll .045" (1.2mm) V knurled groove for flux cored wire 704277
Stick Lead, 200A, 13ft, 50mm Dinse WS200E13
Ground Lead, 200A,10ft, 50mm Dinse WS200G10
Victor Argon Regulator/Flowgauge 0781-4169
Accessory Kit for TIG Torch with 1/16", 3/32", 1/8" thoriated tungstens; 1/16", 3/32", 1/8"
collets; 1/16", 3/32", 1/8" collet bodies; No. 5, 6, 7 Alumina nozzle; short back cap; long
back cap
P062900010
Table 2-2: Fabricator 181i Options and Accessories List
