ULTRA-CUT 100 XT
Manual 0-5272
APPENDIX
A-27
System Bias PCB Test Points
TP1 GND
TP2 24VDC
TP3 DC INPUT POSITIVE
TP4 Vcc1
TP5 Vcc2
TP6 GATE
TP7 PRIMARY GND
TP8 +12V PRIMARY
TP9 P_ISOL_GND
TP10
DC SENSE POSITIVE
LED Reference
D3
Red
MISSING PHASE
D4
Red
AC V HIGH
D14 Red
AC V LOW
D15 Green VAC_IDA
D26 Green +12V PRIMARY
D27 Green VAC_IDB
D30 Green 24VDC
D44 Green TRANSFORMER ON
