Appendix A: Specifications
A-2 WPIM-T1/DDS User’s Guide
A.4 T1 INTERFACE CABLING
This appendix provides the Cabletron Systems part number and connector
information for the Interface Cables used in both the T1 and DDS modes
of the WPIM-T1/DDS.
Table A-1 lists Cabletron Systems part numbers for the interface cables
for T1 mode. A standard 20-foot cable is available or the customer may
specify the length of cable when ordering.
A.4.1 Cable Assemblies and Pinouts
The following section provides connector information for the T1 interface
cable.
Table A-1 Cabletron T1 Cable Part Numbers
Interface Cable Cabletron Part Number
T1 Line Interface Cable 9372094-20
1
1. Standard 20 foot T1 Line Interface Cable.
9372094-L
2
2. (L denotes length required in feet or meters). For example: 9372094-3
denotes a 3 foot cable; 9372094-3M denotes a 3 meter cable.
Table A-2 T1 Connector Information
Cabletron interface cable part number 9372094
Description T1 line interface cable
Connector 1 RJ48C
Connector 2 RJ48C
