Chapter 3: Local Management for T1 Service
3-2 WPIM-T1/DDS User’s Guide
3.1 THE WAN PHYSICAL CONFIGURATION SCREEN
To access the WAN Physical Configuration screen, use the arrow keys to
highlight the WAN SETUP menu item, then press ENTER. The screen
shown in
Figure 3-1 displays.
Figure 3-1 WAN Physical Configuration Screen
NOTE
When there is more than one WPIM installed into the host
platform, information for the second WPIM will display next to
WPIM 1.
SAVE WAN INT CONFIG RETURN
Type: T1
WPIM #: 1
Mgr Type: [PPP]
Max VCs: 024
Next IF: 003
WAN PHYSICAL CONFIGURATION
T1 Timeslot View:
T1 Line Coding:
T1 Frame Type:
T1 Tx Clock Source:
T1 Line Buildout:
T1 Loopback:
WPIM 1 Timeslot Configuration
000 000 000 000 000 000 000 000 01-08
09-16
17-24
WPIM 1 Line Configuration
000 000 000 000 000 000 000 000
000 000 000 000 000 000 000 000
275002
Local Management Flash Image Version: xx.xx.xx
[WPIM 1]
WPIM 1
[Active]
[B8ZS]
[ESF]
[Loop-Timing]
[0 db]
[None]
REMOTE SETUP
