WPIM-T1/DDS User’s Guide 2-1
CHAPTER 2
SETUP AND INSTALLATION
This chapter details set up and installation of the WPIM-T1/DDS into a
host platform.
2.1 INSTALLING THE WPIM-T1/DDS
For additional support related to the WPIM-T1/DDS, refer to the host
platform manual into which the WPIM-T1/DDS is being installed. Locate
the guide by clicking on the Cabletron Systems QuickSET program group
icon after installing the QuickSET CD on your computer, or see
Related
Manuals in the Introduction .
2.1.1 Unpacking the WPIM-T1/DDS
1. Carefully remove the WPIM-T1/DDS from the shipping box.
2. Visually inspect the WPIM-T1/DDS. If there are any signs of damage,
contact Cabletron Systems immediately. Refer to
Getting Help .
Only qualified personnel should install the WPIM-T1/DDS. This
User’s Guide is intended for the experienced network
equipment installer.
NOTE
QuickSET or Local Management must be used to set up the
WPIM-T1/DDS in management before any connections are
made to the WAN. Follow the directions carefully.
NOTE
Some WPIMs require version 1.02 or greater of QuickSET to
participate and function correctly in your network. Contact
Cabletron Systems to obtain the latest version of QuickSET if
you do not have it. Refer to
Getting Help in the Introduction for
more information.
Both the WPIM-T1/DDS and the host platform in which the
WPIM-T1/DDS is installed are static sensitive devices. Use a
grounding strap and follow all static-safe precautions during
installation. Failure to do so could result in damage to the
WPIM-T1/DDS and the host platform receiving it.
