WAN Interface Configuration Screen
WPIM-T1/DDS User’s Guide 4-5
4.2 WAN INTERFACE CONFIGURATION SCREEN
This section describes the features of the WAN Interface Configuration
screen. Access the screen by using the arrow keys to highlight the WAN
INT CONFIG command field at the bottom of the WAN Physical
Configuration screen, then press ENTER. The WAN Interface
Configuration screen shown in
Figure 4-2 displays.
Figure 4-2 WAN Interface Configuration Screen
4.2.1 WAN Interface Configuration Screen Fields
The following sections describe WAN Interface Configuration screen
fields.
Interface Number (Modifiable)
Displays the active Interface Number. Use this field to configure the
Interface Number assigned to the timeslots on the WAN Physical
Configuration screen.
Max Xmit Unit (Modifiable)
User configured field that displays the maximum packet size that can be
transmitted on the selected interface. The default settings for this field
(1526 for PPP and 4095 for Frame Relay) depend on the Protocol
Manager selected.
WAN INTERFACE CONFIGURATION
RETURN SAVE
Interface Number: 000
Max Xmit Unit: 0
ProtMgrIface: [0]
Active Protocol: FR
FR LMI:
[ANSI_94]
DLCI Address: 0
DLCI DCP En:
DLCI DCP Stat:
Comp Ratio:
Circuit State: [Invalid]
