Chapter 4: Local Management for DDS Service
4-2 WPIM-T1/DDS User’s Guide
4.1 THE WAN PHYSICAL CONFIGURATION SCREEN
To access the WAN Physical Configuration screen in Local Management,
use the arrow keys to highlight the WAN SETUP menu item, then press
ENTER. The screen shown in
Figure 4-1 displays, with the
WPIM-T1/DDS in DDS mode.
Figure 4-1 WAN Physical Configuration Screen
4.1.1 WAN Physical Configuration Screen Fields
The following sections describe WAN Physical Configuration screen
fields and provide instructions for setting them. The WAN Physical
Configuration screen lets you configure the WPIM or “Physical
Interface.”
NOTE
When there is more than one WPIM installed into the host
platform, information for the second WPIM will display next to
WPIM 1.
The Type field displays either T1 or DDS, depending on the
mode selected using Network Tools.
SAVE WAN INT CONFIG RETURN
Type: DDS
WPIM #: 1
MgrType: [None]
Max VCs: 000
Next IF: N/A
WAN PHYSICAL CONFIGURATION
DDS Line Mode:
DDS Tx Clock Source:
DDS Loop-Back:
WPIM 1 Line Configuration
2750_01
Local Management Flash Image Version: xx.xx.xx
[WPIM 1]
WPIM 1
[DDS-PRI]
[Loop-Timing]
[NONE] DDS In-Speed:
DDS Out-Speed: 56000
56000
REMOTE SETUP
