The WAN Interface Configuration Screen
WPIM-T1/DDS User’s Guide 3-9
DLCI DCP Stat (Read-Only)
Displays the current negotiated status of compression.
Comp Ratio (Read-Only)
Displays the Compression Ratio, which is the ratio of uncompressed to
compressed data.
Circuit State (Selectable)
The field initially displays the state of the DLCI circuit, and can be
modified. Steps through Active, Inactive and Invalid.
3.2.1.2 PPP as the Protocol Manager
Figure 3-5 WAN Interface Configuration Screen (PPP)
Refer to Figure 3-5 for the following parameters displayed for PPP.
PPP MRU (Modifiable)
Displays the Maximum Receive Units that PPP can handle, modifiable by
the user.
ECP Enable (Toggle)
Toggles between On and Off to enable or disable encryption.
ECP Status (Read-Only)
Displays the status of encryption.
WAN INTERFACE CONFIGURATION
RETURN SAVE
Interface Number: 003
Max Xmit Unit: 1526
ProtMgrIface: [0]
Active Protocol: PPP
PPP MRU: 1520
ECP Enable: [Off]
ECP Status: Off
CCP Enable: [Off]
CCP Status: Off
Comp Ratio: 1:1
2750_02
Local Management Flash Image Version: xx.xx.xx
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
CKT# IF# LID STATE
018
019
020
021
022
023
024
025
026
027
028
029
030
031
032
CKT# IF# LID STATE
016
017 001 Enet UP
002 Enet DOWN
PORTS:
[1-32]
