Timer Operation
The timer operation feature is only available when heating
setpoints, hot tubs, or radiant floors. It is not available when
heating a domestic hot water tank, or pool.
The setpoint control can be set up to normally remain at
the unoccupied temperature setting. The setpoint control
can be activated to temporarily operate at the occupied
temperature for a preset amount of time. This is similar to
a windup timer.
To activate the occupied time on the setpoint control,
press the Up or Down buttons while in the View menu.
The occupied time can also be activated through a remote
enable by pressing the button on a User Switch or through
a tN4 Gateway if these devices are installed.
When using the Up or Down buttons to activate the
occupied time, the amount of time for the occupied time
can be set.
To cancel the occupied time, press and hold the Down arrow
button while in the View until the time displays “OFF”.
The occupied time can also be canceled by pressing the
button on a User Switch or it can be canceled through the
tN4 Gateway if these devices are installed.
Changing the Timer Operation Run Time
When activating the timer operation, the run time starts at
a preset amount of time. To change this preset time:
1. Press the Menu button to select the Scene menu.
2. Press the Item button until the Run Time Occupied item
is selected.
3. Press the Up or Down button to adjust the run time.
Pressing the UP button while in the VIEW menu
starts operation of the Hot Tub for the time set.
To Stop operation press the DOWN button until
the time shows OFF.
Button Enable
Note: Only available for Hot Tub and Floor operation.
User Button 1
User Button 2
User Button 3
UnOcc Occ
Press Button
User Switch Setpoint
Control
Setpoint
Control
Remote Enable
Note: Only available for Setpoint, Hot Tub and Floor
operation.
