Reloop CONTOUR INTERFACE EDITION - Manual (Page 22)

ENGLI
sh
22
OPERATION MANUAL
CAUTION!
For your own safety, please read this operation manual carefully before initial operation! All
persons involved in the installation, setting-up, operation, maintenance and service of this
device must be appropriately qualified and observe this operation manual in detail. This product
complies with the requirements of the applicable European and national regulations. Conformity
has been proven. The respective statements and documents are deposited at the manufacturer.
INDEX
1. setup .............................................................................. 24
1.1 Control Elements ........................................................ 25
1.2 Connections ................................................................. 25
2. Device setup .................................................................... 26
2.1 Basic Steps .................................................................. 26
2.2 Audio Setup ................................................................. 26
2.2.1 Stand Alone Mode ...................................................... 26
2.2.2 External Mixing Mode ................................................ 26
3. Computer Configuration .................................................. 27
3.1 ASIO Driver Installation ............................................ 27
3.2 Traktor LE Setup ......................................................... 28
3.2.1 Installation ................................................................... 28
3.2.2 Configuration ............................................................... 29
3.3 Traktor Pro Configuration (if applicable)................ 29
3.3.1 Audio Setup ................................................................. 29
3.3.2 Mapping Import ........................................................... 30
4. Operation .......................................................................... 32
5. Device settings and Tests .............................................. 36
5.1 MIDI Channel Assignment ......................................... 36
5.2 Jog Wheel Calibration ................................................ 36
5.3 LED Functionality Test ............................................... 37
6. Updates & support .......................................................... 37
7. Appendix ........................................................................... 37
7.1 System Requirements Traktor LE ........................... 37
7.2 MIDI Assignment Map ................................................ 38
7.3 Troubleshooting .......................................................... 41
7.4 Technical Specifications ............................................ 41
Congratulations on purchasing the Reloop Contour Interface Edition. Thank you for placing your
trust in our disc jockey technology. Before operating this equipment we ask you to carefully study
and observe all instructions.
Please remove the Reloop Contour Interface Edition from its packaging. Before initial operation
please make sure that the device has not been visibly damaged during transport. If you detect any
damage to the power cable or the casing, do not operate the device and contact your specialised
dealer.
sAFETY INsTRUCTIONs
CAUTION!
Please exercise particular caution when handling the power voltage. This voltage rating may
lead to a critical electrical shock! Any damage caused by the non-observance of this operation
manual excludes any warranty claims. The manufacturer is not liable for any damage to proper-
ty or for personal injury caused by improper handling or non-observance of the safety instruc-
tions.
- This device has left the factory in perfect condition. To maintain this condition and to ensure a
risk-free operation the user must observe the safety instructions and warnings contained in this
operation manual.
- For reasons of safety and certification (CE) the unauthorised conversion and/or modification of
