18. Center the elevator and mark the pushrod. Bend

the pushrod and attach it to the elevator servo
arm using a pushrod wire keeper. Trim the
elevator servo arm as shown in the photo.

Note:.Ensure.the.radio.is.turned.on.with..

the.trims.and.sub-trims.centered.and.the..

servos.are.centered.



19. Repeat Step 14 through 16 to attach the

remaining elevator half. Pass the pushrod
through the wheel collars when installing
the pushrod.

Note:.It.may.be.necessary.to.trim.the.length.of.

the.pushrod.wire.
