8 E-flite Hawker Sea Fury 480 ARF Assembly Manual
 2. Prepare the aileron servos by installing the servo
arms on the servos. Use your radio to center these
servos at this time.
 3. Apply a piece of double-sided tape onto each
servo, on the side opposite the servo arm.
 4. Remove the backing from the double-sided tape.
Position the servo so the arm is facing toward the
aileron and the outboard side off the wing. Press
each aileron servo into the openings in the wing.
 5. Connect a 6-inch (152mm) extension to each
aileron servo lead. If you have opted to install
retracts, attach a 9-inch (228mm) extension to
each retract servo lead. Use string to secure the
extension(s) so they do not unplug accidentally.
 6. Route the leads for the aileron (and retract)
servo(s) along the channel in the wing. The
extension(s) then pass to the top of the wing
through the hole in the center of the wing.
 7. Remove the backing from the double-sided tape
on the wing cover.
